ThermaGon
Thermoset Halogen-Free Flame-Retardant (HFFR) Compounds
for 125º C Applications
| ThermaGon Compound | LOI | Tensile at Break, psi (MPa) | Elongation at Break, % | Specific Gravity g/cc | Features | MSDS |
| EXL 0145 | 28 | 2475 (17.1) | 280 | 1.40 | Chemically crosslinkable. Primary insulation for low voltage automotive and 125º C appliance wire. Formulated to pass requirements of SAE J1128 and UL 125º C applications. Scorch resistant, good processibility. Supplied as natural color. Can be supplied in white, black or custom colors upon request. |
 |
| EBR 0146 | 27 | 2400 (16.5) | 260 | 1.40 | Radiation curable. Primary insulation for low voltage automotive and 125º C appliance wire. Formulated to pass requirements of SAE J1128 and UL 125º C applications. Good processibility. Supplied as natural color. Can be supplied in white, black or custom colors upon request. |
|
| EXL 0500 | 48 | 2100 (14.5) | 200 | 1.57 | Chemically crosslinkable. For demanding 125º C applications requiring high flame-retardant properties and good electrical properties. Recommended for jacketing industrial, low voltage and medium voltage power cables. Supplied as natural color. Can be supplied in white, black or custom colors upon request. |
|
Click here to download a free copy of Adobe Reader which you will need to read the MSDS documents.
